Broadband Directional Antenna

800-2100 MHz FXLP800X3 (1Y05900)

The FXLP800X3 is a broadband log periodic antenna that covers the entire band of 800-2100 MHz. It is designed to achieve the maximum gain with minimum size and robust construction for harsh environments.

ELECTRICAL:

  •  Frequency Range: 800-2100 MHz
  •  Gain: See Charts
  •  VSWR: < 2.5:1
  •  Input Impedance: 50 Ω Nominal
  •  Power: 50 Watts
  •  Polarization: Horizontal or Vertical
  •  Front-to-Back Ratio: See Charts
  •  Input Connector: SMA Female

MECHANICAL:

  •  Boom Length: 17.62 in. (0.45 m)
  •  Element Span: 8.88 in. (0.23 m)
  •  Number Of Elements: 10 Elements
  •  Color: Black/Green/Tan/Grey
