Handheld Directional Antenna

136-174 MHz TDLP136-174

The TDLP136-174 is a handheld tracking antenna designed for specific frequency bands. This antenna has folding elements that are secured with a strap when not in use. The antenna can be stowed in a heavy duty canvas holster (sold separately) that attaches to the user’s belt or web gear.

ELECTRICAL:

  •  Frequency Range: 136-174 MHz
  •  Gain: 6.0 dBi Nominal
  •  VSWR: < 2.25:1
  •  Input Impedance: 50 Ω Nominal
  •  Power: 100 Watts
  •  Polarization: Directional
  •  Beam Width: Azimuth: 74°
  •  Input Connector: TNC Female

MECHANICAL:

  •  Boom Length: 22.36 in. (0.56 m)
  •  Element Span: 37.38 in. (0.95 m)
  •  Number Of Elements: 3 Elements
  •  Net Weight: 2 lb. (0.91 kg)
  •  Color: Black/Green/Tan/Grey
